YINJIA is a professional China in-line pump vertical manufacturer and supplier, if you are looking for the best in-line pump vertical with low price, consult us now! CMN series In-line pump vertical,is a popular boosting pump in the global market, like single phase and three phase both popular in Singapore for project. The light and compact in-line pump can be mounted in the pipeline without requiring a large footprint. They are used to pump hot water and chilled water for heating system/air conditioning and cooling.
APPLICATIONS
-Hot or chilled water cirulating systems
-Refrigerating systems
-Domestic and potable water systems
-Industrial water services
-Circulation and supply of potable, domestic, sanitary, brackish
-Water and other clean agressive liquids
DESIGN FEATURES
-SUS304 for pump body, impeller,seal housing, motor shaft
-Cast iron motor bracket
-Aluminium rear cover
-Bearing: SKF
-100% copper winding
-Mechanical seal: Carbon/Sic/EPDM/SUS304
OPERATING LIMITS
-Max. operating pressure: 6 bar
-Max. ambient temperature: +40℃
-Liquid temperature from -10℃ to +110℃
-Max. viscosity: 2E
-Specific gravity: 1kg/m³
MOTOR
-Insultation class: F
-Protection: IP44
-Speed of rotation: 2850rpm
-Continuous service
PERFORMANCE CHART
PERFORMANCE DATA
DIMENSIONS
CMN SERIES EXPLODING DRAWING
